SPECIFICATION：

Measuring Range
axial length   14-38mm
Corneal curvature    5-11mm
Anterior chamber depth    0.7-8mm
Lens thickness   1-10mm(lens)    0.13-2.5mm(intraocular lens)
Center cornea thickness    0.2-1.2mm
Cornea white to white    7-16mm
Pupil diameter     2-13mm
urvature range     180 degree
Accuracy
Axial length    0.01mm
Corneal curvature    0.01mm
Anterior chamber depth   0.01mm
Lens thickness    0.01mm
Center cornea thickness    0.01mm
White to white    0.1mm
Pupil diameter    0.01mm
Axis of sight eccentricity   0.01mm
Axis angle    1 degree
Repeatability
Axial length   0.02mm
Corneal curvature   (1ρ)+/-30um
Anterior chamber depth   0.02mm
Lens thickness   0.02mm
Center cornea thickness   0.02mm
White to white    (1a)+/-0.3um
curvature difference   +9 degree

Calculation formula of intraocular lens
BinkHorst-ll、Holladay、Hoffer-Q、Haigis、SRK-T、SRK II

interfaces
USB2.0 window 10

voltage/lfrequency
AC 110-240V/50HZ
